Description
PRODUCT DESCRIPTION
Dimensions: 96.8mm (L) x 34.5mm (H) x 37.4mm (D)
Features:
- Super wide-angle output rated with SAE and ECE R65 Class 1.
- Versatile Surface Mount with or without bezel, suitable for all vehicle bodies and motorcycle storage boxes.
- Non-volatile memory recalls last flash pattern used at power up.
- Multi-units synchronization in simultaneous or alternating flash.
- Reverse polarity protection.
- Fully weatherproof and vibration resistant design for external or internal use.
- Aluminum base for efficient heat dissipation and maximum durability.
Specifications:
- Meets: SAE J595 & J845 (R,A,B,W), IPX7, ECE R65 (XA1, XB1), ECE R10
- Bulb: High-power LED x 6pcs
- Warning Patterns: 16 Flash Patterns
- Operating Voltage: 12~24VDC
- Avg. Current: 0.57A @12VDC / 0.285A @24VDC (varies with flash pattern)
- Avg. Power: 6.84 Watts (varies with flash pattern)
- Max. Current: 1.14A @12VDC / 0.57A @24VDC
- Max. Power: 13.7 Watts
- Wires: Red-Vcc : 20cm (20AWG) / Black-GND : 20cm (20AWG) / Yellow-Flash Patterns & Sync : 20cm (20AWG)
- Fuse Recommended: 2A
- Multi-Unit Synchronization: Over 15 units
- Available in: RED, BLUE, AMBER, WHITE
