Description
PRODUCT DESCRIPTION
Dimensions: 85.6mm (L) x 27.7mm (H) x 15.7mm (D)
Features:
- Super low profile for discreet mounting.
- Multi-Voltage Input 12~24VDC.
- Built-in 12 Selectable Flash Patterns.
- LEDs rated to 100,000 hours of operation.
- Non-volatile memory recalls last flash pattern used at power up.
- Multi-units synchronization.
- Reverse polarity protection.
- Weatherproof and vibration resistant design for versatile application.
- Aluminum base for efficient heat dissipation.
Specifications:
- Meets: SAE, CA13, e13
- Bulb: 1W LED x 3pcs
- Warning Patterns: 12 Flash Patterns
- Operating Voltage: 12~24VDC
- Avg. Current: 0.2A @12.8VDC / 0.11A @24VDC
- Avg. Power: 2.7 Watts
- Max. Current: 0.4A @12.8VDC / 0.22A @24VDC
- Max. Power: 5.5 Watts
- Wires: Red-Vcc: 97cm (20AWG) / Black-GND: 97cm (20AWG) / Yellow-Flash Patterns & Sync: 97cm (20AWG)
- Fuse Recommended: 3A
- Multi-Unit Synchronization: Over 15 units
- Available in: RED, BLUE, AMBER, WHITE
