PRODUCT DESCRIPTION
Dimensions: 98.54mm (L) x 35.07mm (H) x 10mm (D)
Features:
- 6LED+6LED Dual colour.
- SAE Class 1 high power output.
- ECE R10 EMC Compliance.
- 0.68” (17.2mm) low-profile thickness.
- Long life LEDs rated to 100,000 hours of operation.
- Non-volatile memory recalls last flash pattern used at power up.
- Multi-units synchronization in simultaneous or alternating flash.
- Reverse polarity protection.
- Weatherproof and vibration resistant design for internal or external use.
- Aluminum base for efficient heat dissipation.
Specifications:
- Meets: SAE J595, CA13 (R/B/Y), ECE R10-04
- Bulb: High-power LED x 12pcs
- Warning Patterns: 12 Flash Patterns
- Operating Voltage: 12~24VDC
- Avg. Current: 0.6A@12VDC / 0.3A@24VDC
- Avg. Power: 7.2W
- Max. Current: 1.2A@12VDC / 0.6A@24VDC
- Max. Power: 14.4W
- Wires: Red-Vcc : 20cm (20AWG) / White-Vcc : 20cm (20AWG) / Black-GND : 20cm (20AWG) / Yellow-Flash Patterns & Sync : 20cm (20AWG)
- Fuse Recommended: 2A
- Multi-Unit Synchronization: Over 15 units
- Available in: BLUE, AMBER, RED, WHITE
